Skyline 29 Carbon Fiber Mountain Wheels

Description:

Internally called the "no holds barred" rim, this rim is the result of almost a year of R&D efforts to push the limits of weight, stiffness and durability available in a carbon rim. Our goal was to make the ultimate XC racing rim on the planet (yes, we set our sights high!). What our engineers came up with delivers; with an abundance of lateral stiffness, our trademark asymmetrical design, generous 23mm inner width and a continued refinement of our Rockguard Hookless bead provides best in the industry durability to rock strikes or other direct rim impacts. In short, if you are looking for speed, a wheelset built around the Skyline rims is the best upgrade you can make for your bike.

We offer the Skyline 29 as a single rim or a complete wheelset. Our wheelsets are handbuilt right here in Tennessee using only the best components; Sapim CX-Ray or Race spokes and DT Swiss alloy Pro Lock squorx nipples. Hub choices include Chris King, Industry Nine, Hope, DT Swiss and Project 321. To see a comparison of all our hubs check out the hub comparison chart. Wheel builds come with our TPP tape and tubeless valves installed. All wheelsets are built to order and it may take 4 weeks or more depending on hub availability.

Wheels are handbuilt in Tennessee

Uniweave construction blends two composite fabric types, 3K and Unidirectional to create the strongest structure possible.

The RockGuard HL bead is a reinforced hookless bead designed to provide the ultimate in bead strength for AM applications.

The Anti-Burp Bump makes initial tire inflation easier and prevents burping on the trail.

Handbuilt wheelsets from $1,382 (DT350)

Most rims are in stock and ship in 1-3 days. Custom wheel builds take 4 weeks or more depending upon hub availability. Any cancelled complete wheelset orders are subject to a cancellation fee as high as 20% depending on if the wheel has been built. For pricing or to configure a wheelset, use the drop down menu below. We only recommend using tires intended for hookless rims on the Skyline 29. Though the Skyline can work safely with tires up to 2.5", the rim works best with tire widths ranging from 33mm-2.25".
FREE SHIPPING ON WHEELSETS

Skyline 29 Specifications
Rim weights are +/- 10g Wheel weights are with CX-Ray spokes with alloy nipples **Recommended build tension is 120 kgf Please read the FAQ for other questions.
Weight Rim		345g*
Weight I9 Wheelset		1399g**
Weight Hope Wheelset		1476g**
Weight King Wheelset		1478g**
Weight DT 240S Wheelset		1384g**
Weight Project 321 Wheelset		1432g**
Weight DT 350 Wheelset		1451g**
Weight Onyx Wheelset		1667g**
ERD		598
Asymmetric Offset		2.6mm
Spoke Hole Drilling		Asymmetric, 5 deg
Max Tension		160 kgf***
Depth		22mm
Width		29mm external, 23mm internal
Hole Count		32, 28, 24
Tubeless Ready		Yes
Finish		Satin Unidirectional Carbon
Tech Features		UniWeave™, RockGuard HL™, Anti-Burp Bump™
Rider Weight Limit		220 lbs
